Milandr K1886VE2U PIC17C756A w/ Flash Memory

We have previously talked about the Microchip PIC17, and its less then stellar success in the market.  After being introduced in the early 1990’s it was discontinued in the early 2000’s, though Microchip continued to provide support (and some devices) to users for some time after that.

In the early 1990’s a IC company was formed in Zelenograd, Russia (just a short distance to the NW of Moscow), the silicon valley of Russia, home to the Angstrem, and Micron IC design houses.  This company was Milandr, one of the first post-Soviet IC companies, with ambitious plans, and many highly capable engineers from the Soviet times.  They are a fabless company, though with their own packaging/test facilities, specializing in high reliability metal/ceramic packages.

The K1886VE is Milandr’s version of a PIC17C756A, though updated for the 21st century.  While mask-ROM versions are available the VE2 version replaces the ROM with modern FLASH memory.  This is a upgrade that perhaps would have kept the PIC17 alive if Microchip would have done similar.  It is packaged in a 64 pins CQFP white ceramic package with a metal lid and gold leads, not what one is use to seeing a PIC in.  Production of these PICs continues at Milandr (the pictured example is from 2012), as customers still use the parts, mainly in industrial and other places where reliability is key.

The use of a PIC in high reliability applications isn’t something entirely new.  The Microhard MHX-2400 radio system, designed for small satellites such as cubesats, runs on a PIC17C756A, a version flew on NASA’s Genesat-1 in 2006 carrying bacteria samples.  Milandr does offer radiation resistant devices so its likely that some Milandr PIC has flown to space as well.

Akatsuki – Though by now its main antenna is probably brown or black from being baked by the sun – Powered by a NEC uPD55117B-018 16-bit processor.

Akatsuki, Japanese for Dawn, was launched in May of 2010 for a journey to the morning star, Venus, on a JAXA H-IIA rocket. The H-IIA flight computer runs on a space rated version of the NEC V70 32-bit processor, running the NEC RX616 RTOS.  A processor significantly faster than that of the interplanetary probe it was launching.

“it will have a short cruise to Venus, entering its long, elliptical orbit in December. Its mission should last several years. “

In space, things don’t always go as planned…

On December 7th Akatsuki entered orbit around Venus, December of 2015 rather than 2010.  Due to a valve in the fuel pressurization system not opening all the way the orbital insertion engine ran much too lean on its attempt to enter orbit, causing it to overheat and catastrophically fail.  This left the probe on a heliocentric orbit, moving away from Venus.  The Japanese Space Administration (JAXA) was not deterred, Akatsuki’s orbit would eventually meet up with Venus again, almost exactly 5 years later.  JAXA determined they could use the probes attitude control thrusters, which feed off the same fuel tank as the failed main thruster, to insert Akatsuki into a highly elliptical, yet still useful orbit.  Had the Attitude control system used a separate fuel system (which is actually the more common design method) this would not have been possible, as it would take a relatively large amount of fuel, fuel that was available on Akatsuki due to the main engine failing and being shut down before its burn was completed.  It should be noted that such a maneuver had never previously been even proposed, let alone attempted.  There was however another small problem…

Read More »

Dawn’s mission: Ceres

Dawn was launched in 2007 by NASA/JPL and was built by Orbital Sciences becoming their first interplanetary spacecraft.  Dawns mission was to visit the two largest dwarf planets in the Asteroid belt, Vesta and Ceres.  After visiting Vesta for over a year in 2011-2012 Dawn used its ion engines to break orbit, and travel to Ceres, a journey of 2.5 years.

In the next few hours Dawn will be captured by Ceres gravity and begin orbiting it.  These protoplanets, are very interesting scientifically as they provide a look into our solar systems past.  Dawn will orbit Ceres for several years and perhaps discover what the mysterious bright spots are, among other things.  Studying a planet, even a dwarf planet, requires processing power, and for that Dawn is well equipped.

Dawn is solar powered, so power budgets are of great concern.  At 3AU (three times further from the sun then Earth) Dawns solar panels are rates at about 1300 Watts.  This has to run all the science experiments, the main computers, the comms, and most importantly the electric ion engine, which uses electricity generated from the panels to excite and eject Xenon gas at very high velocities.  Thus, power consumption is more important then raw processor power here, especially for the systems that are on most of the time.

Read More »

Comet 67P/Churyumov–Gerasimenko – Soon to have a pair of Harris RTX2010 Processors

In less then an hour (11/12/2014 @ approx 0835 GMT) 511,000,000 km from Earth the Philae lander of the Rosetta mission will detach and begin its decent to a comets surface.  The orbiter is powered by a 1750A processor by Dynex (as we previously discussed).  The lander is powered by two 8MHz Harris RTX2010 16-bit stack processors, again a design dating back to the 1980’s.  These are used by the Philae CDMS (COmmand and Data Management System) to control all aspects of the lander.

All lander functions have to be pre programmed and executed by the CDMS with absolute fault tolerance as communications to Earth take over 28 minutes one way.  The pair of RTX2010s run in a hot redundant set up, where one board (Data Processing Unit) runs as the primary, while the second monitors it, ready to take over if any anomaly is detected.  The backup has been well tested as on each power cycle of Philae the backup computer has started, then handed control over to the primary.  This technically is an anomaly, as the CDMS was not programmed to do so, but due to some unknown cause it is working in such a state.  The fault tolerant programming handles such a situation gracefully and it will have no effect on Philae’s mission.

Why was the RTX2010 chosen?  Simply put the RTX2010 is the lowest power budget processor available that is radiation hardened, and powerful enough to handle the complex landing procedure.  Philae runs on batteries for the first phase of its mission (later it will switch to solar/back up batteries) so the power budget is critical.  The RTX2010 is a Forth based stack processor which allows for very efficient coding, again useful for a low power budget.

Eight of the instruments are also powered by a RTX2010s, making 10 total (running at between 8-10MHz).  The lander also includes an Analog Devices ADSP-21020 and a pair of 80C3x microcontrollers as well as multiple FPGAs.

Rosetta Comet Chaser – Dynex 1750

The ESA’s comet chaser Rosetta has just today awoken from a long deep sleep on its comet chasing (and landing) mission.  The solar powered spacecraft was launched back in 2004.  It is based on the Mars Mariner II (itself based on the Voyager and Galileo) spacecraft design of the early 1990s (when the mission was first conceived.)  Main differences include using very large solar arrays versus a RT (Radioisotope Thermal Generator) and upgraded electronics.

In order to conserve power on its outward loop (near Jupiter’s orbit) most all systems were put to sleep in June of 2011 and a task set on the main computer to waken the spacecraft 2.5 years later and call home.  The computer in charge of that is powered by a Dynex MAS31750 16-bit processor running at 25MHz, based on the MIL-STD-1750A architecture.

A reader recently asked why such an old CPU design is still being used rather then say an x86 processor.  As mentioned above the Rosetta design was began in the 1990’s, the 1750A was THE standard high reliability processor at the time, so it wasn’t as out of date as it is now that its been flying through space for 10 years (and 10 years in the clean room).  The 1750A is also an open architecture, no licenses are or were required to develop a processor to support it (unlike x86). Modern designs do use more modern processors such as PowerPC based CPUs like the RAD750 and its older cousin the RAD6000.  Space system electronics will always lag current tech due to the very long lead times in their design (it may be 10 years of design n the ground before it flies, and the main computer is selected early on).  x86 is used in systems with 1) lots of power, and 2) somewhat easily accessible.  Notably the International Space Station and Hubble.  x86 was not designed with high reliability and radiation tolerance in mind, meaning other methods (hardware/software) have to be used to ensure it works in space.

Currently the ESA designs with an open-source processor known as the LEON, which is SPARC-V8 based.
